| Headstock |
Quilted maple front, figured bubinga back. Mother of pearl and abalone inlayed logo (front). Zircote truss rod cover with abalone inlayed maple leaf. |
| Neck |
7 piece; mahogany, curly maple, wenge, purpleheart, wenge, curly maple, mahogany. Double action truss rod. |
| Fretboard |
Macassar ebony with custom abalone inlays. Curly maple binding. |
| Body |
Figured mahogany chambered body with 1/4" quilted maple drop top. Wenge trim. Zircote control cavity cover. |
| Finish |
Water-based lacquer. |
| Tuners |
Cosmo black Gotoh 510 tuners. |
| Pickups |
Lindy Fralin pure PAF humbucker pickups with bubinga pickup covers and mounting rings. |
| Controls |
3 position switch (partial tap, humbucking, single coil) for each pickup. Push-pull master volume knob to switch on and route through the preamplifier. Balance (humbucking pickup selector) knob. Piezo pickup volume knob. Humbucker / piezo selector switch. Stereo wiring. Copper shielded control cavity. |
| Bridge |
Ruthenium Schaller Hannes piezo bridge with flagship preamp. |
| Misc. |
Ruthenium Schaller Strap Locks. TKL VTR-530 case. |
|
| Scale Length |
25" |
| Fretboard Radius |
12" |
| Nut Width |
1 3/4" |
| Neck Profile |
Round |
)
)
)
)
)
)
)
)
